| Place of Origin: | China |
|---|---|
| Hàng hiệu: | OPTFOCUS |
| Chứng nhận: | ROHS |
| Model Number: | OFS-FTH-JS5 |
| Minimum Order Quantity: | 10 pcs |
| Giá bán: | negotiated |
| Packaging Details: | Carton Size(cm):84*43*34 Qty/CTN:10PCS G.W/CTN:21KG |
| Delivery Time: | 5-8 days afterpayment received |
| Payment Terms: | Western Union, T/T, L/C, Paypal |
| Supply Ability: | 10000PCS/Month |
| Material: | Engineering Plastics | Color: | black |
|---|---|---|---|
| Splitter: | 1x16SC or 2x32 LC | Core capacity (max): | 48cores |
| Adapter Type: | SC or LC | Weight: | 6.5KG |
| Điểm nổi bật: | electrical enclosures,fiber enclosure |
||
Dome Mechanical Seal Splitter Splice Closure
Description
The OFS-FTH-SM4 is a small size specialized designed for FTTx application.
The product adopts fully-mechanical sealing structure. It can be used for Install PLC splitter application, as well as passive optical fiber distribution.
Features
ü · Made from engineering plastic with high strength and anti-corrosion.
ü ·Reinforce rebar on the body of closure make excellent performace under impact, pulling, tension etc
ü ·Convenient to increase or reduce trays/ cassette for capacity requirement
ü ·Spacious storing tray/ cassette for storing and maintainance
ü ·3 fixing item/designs to prevent fiber cable from external effect
ü ·Can be used from -40°C to +65°C temperature range
ü ·Easy to re-enter without tools
ü ·Intergrated seal, air tight and water proof, flame-retarded
ü ·Exquisite small size design, convenience installation application
ü · available 1 pcs of 1x8 or 1x16(LC duplex) splitter.
ü · Suitable for wall-mounting or pole mounting application
ü ·4 pcs of small round port
ü · suitable for mini module type of PLC splitter with SC connector or LC connector, etc
ü · Sealing method: mechanical sealing type
Application
ü · FTTH, FTTB, FTTC
ü · Telecommunication Network
ü · CATV
ü · Local Area Network
|
Item No. |
Dimension (D×H)mm |
Cable Entry Ports |
Cable Diameter mm |
Max.Capacity (bunchy fiber) |
No. of Tray |
REMARK |
|
OFS-FTH-SM4 |
Φ178×288 |
4 |
4 ports for Max. Φ16 |
12 |
1-2 |
mechanical seal 1x8PLC (SC) |
Standard Accessories: one set of wrench, metal hoop, earthing wire, nylon tie, labeling paper, splicing sleeves, sealing tape, insulation tape, emery cloth, wrench for reinforce core, 1M buffer tubeOptional Accessories: earthing device, air-pressure test valve
1,HHeight (295mmm) 2,IInside height(285mmm)
3,Splice tr ay width (91mm) 4,Splice tr ay height (1114mm)
5,Inside deepth(60m m) 6,IInlet hole(4ppcs φ5~φ18)
